4 PON Ports GPON OLT

Dimension(mm):442*220*44(L×W×H)

Weight:2.8kg

Features
Specification
Application
Video

4 PON Ports GPON OLT

PTF3704E


Overview:

PTF3704E GPON OLT provides 4 GPON ports, 4*GE+2*GE(SFP)/10GE(SFP+) uplink ports. It has high reliability, high density and powerful switching and routing abilities. It is a new generation of broadband multi-service access OLT equipment for service integrated network.

PTF3704E OLT integrates with network security, supports data, voice and video, and provides continuous forwarding, graceful restarting and ring protection, improving the work efficiency and securing the maximum running time.

1U height 19 inch rack mount product with 4 PON ports, each port supports up to 128 ONUs, the whole device supports up to 512 ONUs. Small size and high density OLT, easy to install, convenient, flexible and easy to deploy high performance broadband access network. It can be deployed in compact room environment, and can also be used for “Triple-Play” VPN, IP Camera, Enterprise LAN and ICT applications.


Features:

Ø 1U 19 inch standard chassis GPON OLT with 4PON ports

Ø Compliant with ITU-T G984/G.988 standards and China Telecom GPON Technical Requirements

Ø Friendly EMS/Web/Telnet/CLI management

Ø 16K Mac address

Ø Open to any brand of OLT

Ø Support 4096 VLANs, port VLAN and protocol VLAN

Ø Support VLAN tag/Un-tag ,VLAN transparent transmission

Ø Support VLAN translation and QinQ

Ø Support storm control based on port

Ø Support port isolation

Ø Support port rate limitation

Ø Support 802.1D and 802.1W

Ø Support static LACP

Ø QoS based on port, VID, TOS and MAC address

Ø Access control list

Ø IEEE802.x flow control

Ø Port stability statistic and monitoring

Ø QoS based on port, VID, TOS and MAC address

Ø Support IGMP snooping, 256 IP Multicast Groups

Ø DHCP server,DHCP relay,DHCP snooping

Ø Support data encryption, multi-cast, port VLAN, separation, RSTP, etc

Ø Support ONT auto-discovery, auto configuration/link detection/remote upgrade of software

Ø Support VLAN division and user separation to avoid broadcast storm

Ø Support power-off alarm function, easy for link problem detection

Ø Support broadcasting storm resistance function

Ø Support port isolation between different ports

Ø Support ACL and SNMP to configure data packet filter flexibly

Ø Specialized design for system breakdown prevention to maintain stable system

Ø Support RSTP,IGMP Proxy

Ø Tcont DBA, Gemport traffic

Ø Support Dynamic Bandwidth Allocation (DBA)

Ø Support remote software upgrade,download ONT firmware to OLT from web/tftp/ftp

Ø Two power supply redundancy design to improve reliability

Items

Unit

Specifications

PON standard

GPON ITU-T G.984.x, G.988

PON interface

Qty.

4*GPON SFP Ports (Class C+),  Receiving sensitivity: ≤ -30dBm(Saturation Optical -12dBm). Power,Transmitting optical power: +3~+7dBmTransmission distance: 20KM. Max splitting ratio1:128

Speed

Upstream 2.488G

Downstream 1.244G

Wavelength

nm

Tx1310, Rx 1490

Uplink

GE

4*GE(copper Ethernet)

SFP GE

SFP 10GE

2*GE(SFP)/10GE (SFP+) auto-detection

Layer 3

Support static route, RIP v1/v2, OSFP v2, ARP proxy

Management Ports

1*10/100BASE-T out-band port, 1*CONSOLE port

Management Mode

SNMP, Telnet, CLI, WEB

VLAN

Tag / Un-tag,VLAN transmission,QinQ

Operating condition

Operating temp: 0 ~ +50

Storing condition

Storing temp: -40 ~ +85

Humidity

%

5~90(non-condensing)

Power Supply

AC

100~240V, 47/63Hz, (DC:-48V optional)

Power consumption

W

≤45

Dimension

mm

442*220*44(L×W×H)

Net weight

Kg

2.8

Shipping packaging:

Description

Quantity

Weight

Carton Size

Shipping packaging

1pcs /ctn

5kg/ctn

575*380*115mm

5pcs /ctn

25.5kg/ctn

597*402*645mm
